Steel

Hot dipped galvanized steel wire

Short Description:

Product Name: Galvanized steel wire/Black annealed wire

Galvanized steel wire is made by drawing high-quality carbon structural steel and then heat-treating and galvanizing it

Raw material: Mild steel, stainless steel, carbon steel

Grade: Q195, Q235, SAE1006, SAE1008 etc

Surface: Hot-dip galvanized, Electro-galvanized

Diameter: 0.15-20mm

Tensile strength: 30-50kg/mm2 also as customer’s requests

Standard: GB/T6893-2000, GB/T4437-2000, ASTM B210, ASTM B241, ASTM B234, JIS H4080-2006, etc

Application: widely used in various fields such as construction, handicrafts, weaving wire mesh, highway guardrails, product packaging and daily civil use


Product Detail

Product Tags

Overview of Galvanized Wire

Galvanized wire is made of high-quality low-carbon steel wire rod, which is divided into hot-dip galvanized wire and cold-galvanized wire.

Hot dip galvanizing is dipped into a heated molten zinc solution. The production speed is fast, the consumption of zinc metal is large, and the corrosion resistance is good.

Cold galvanizing (electro-galvanizing) is to gradually coat the metal surface with zinc through a unidirectional current in the electroplating tank. The production speed is slow, the coating is uniform, the thickness is thin, the appearance is bright, and the corrosion resistance is poor.



Overview of Black Annealed Wire

Black annealed wire is another cold-processed product of steel wire, and the material used is generally high-quality low-carbon steel or stainless steel.

It has good elasticity and flexibility, and its softness and hardness can be controlled during the annealing process. The wire number is mainly 5#-38# (wire length 0.17-4.5mm), which is softer than ordinary black iron wire, more flexible, uniform in softness and consistent in color.

jindalai-steel wire-gi wire -steel rope (21)

Specification of High Tensile Hot dipped galvanized steel wire

Product Name High Tensile Hot dipped galvanized steel wire
Production Standard ASTM B498(Steel Core Wire For ACSR); GB/T 3428(Over Stranded Conductor or Aerial Wire Strand ); GB/T 17101 YB/4026(Fence Wire Strand); YB/T5033(Cotton Baling Wire Standard)
Raw Material High carbon wire rod 45#,55#,65#,70#,SWRH 77B, SWRH 82B
Wire Diameter 0.15mm—20mm
Zinc Coating 45g-300g/m2
Tensile Strength 900-2200g/m2
Packing 50-200kg in Coil Wire, and 100-300kg Metal Spool.
Usage Steel Core Wire for ACSR, Cotton Balling Wire, Cattle Fence Wire. Vegetable House Wire. Spring Wire and Wire Ropes.
Feature High Tensile Strength, Good Elongation and Yiled Strength. Good Zinc Adhesive

jindalai-steel wire-gi wire -steel rope (17)
